Standard Power Cable is a reliable and economical solution for general industrial power transmission. This Standard Power Cable uses high quality PVC insulation and jacket, offering good flexibility and flame retardant performance for indoor drag chain applications. It supports various core sizes and meets basic industrial safety requirements.
This Standard Power Cable is easy to install and compatible with most light to medium automation equipment. It delivers stable voltage output and long service life in low dynamic environments. We offer bulk packaging, global shipping, and full certification support for mass production projects.
CF885 Service life guaranteed by warranty commitment
|
Dual circulation |
5Million Times |
7.5Million Times |
10Million Times |
||||
|
Applicable Temperature Range[°C] |
Max Speed [m/s] |
Max Acceleration [m/s2] |
Travel Distance [m] |
R min. [Coefficient x d] |
R min. [Coefficient x d] |
R min. [Coefficient x d] |
|
|
Overhead |
|
|
|
|
|
||
|
+5/+15 |
3 |
20 |
≤10 |
17.5 |
18.5 |
19.5 |
|
|
+15/+60 |
15 |
16 |
17 |
||||
|
+70/+70 |
17.5 |
18.5 |
19.5 |
||||
|
In practical applications, it can achieve a higher number of dual cycles. |
|||||||
Product Code,Number Of Core Wires And Cross-Sectional Area,Maximum Outer Diameter,Copper Content,Weight
Typical Application Scenarios
• Flexible load requirements
• Oil-incompatible
• Recommended for indoor use
• Particularly suitable for horizontal overhead applications
• Woodworking machinery, stone processing equipment, packaging industry, supply systems, logistics equipment, and regulatory facilities
CF30 Service life guaranteed by warranty commitment
|
Dual circulation |
5Million Times |
7.5Million Times |
10Million Times |
|||||
|
Applicable Temperature Range[°C] |
Max Speed [m/s] |
Max Acceleration [m/s2] |
Travel Distance [m] |
R min. [Coefficient x d] |
R min. [Coefficient x d] |
R min. [Coefficient x d] |
||
|
Overhead |
Glide |
|
|
|
|
|
||
|
-5/+5 |
10 |
5 |
80 |
≤100 |
10 |
11 |
12 |
|
|
+5/+60 |
7.5 |
8.5 |
9.5 |
|||||
|
+60/+70 |
10 |
11 |
12 |
|||||
|
In practical applications, it can achieve a higher number of dual cycles. |
||||||||
Product Code,Number Of Core Wires And Cross-Sectional Area,Maximum Outer Diameter,Copper Content,Weight
Typical Application Scenarios
• For extremely high loads
• Mild oil resistance
• For indoor use, also suitable for outdoor applications when the ambient temperature exceeds 5°C.
• Suitable for overhead applications and taxiing applications with a travel distance of less than 100 meters.
• Elevated warehouse storage and retrieval equipment, processing equipment/machining tools, Logistics equipment, indoor cranes
Features
• Standard Power Cable is built with flexible multi-strand bare copper conductors and PVC insulation & jacket for general industrial power transmission.
• It uses a short-pitch stranding structure to improve bending performance in light-duty drag chains.
• Operating temperature ranges from +5°C to +70°C, with a rated voltage of 600/1000V and a minimum bending radius of 7.5×D to 15×D depending on load level.
• It is flame-retardant, silicone-free, and RoHS compliant, suitable for fixed and dynamic indoor applications.
Advantages
• Standard Power Cable provides stable electrical performance at an economical cost, making it the most widely used solution for conventional machinery and automation lines.
• The soft PVC structure allows smooth bending and routing in cabinets, drag chains, and equipment with limited installation space.
• It runs reliably in dry, indoor, non oily workshops with almost no daily maintenance, lowering long term operating costs.
FAQ
Can your Standard Power Cable be used in indoor automation equipment?
Yes, this Standard Power Cable is widely used in indoor machinery, conveyors, and general electrical equipment.
Is your Standard Power Cable flame-retardant and safe?
This Standard Power Cable is flame-retardant, low-smoke, and meets industrial safety standards for stable operation.
